Machine shop

Lathe
Table Design
Specifications
Machine Center Height Spindle Bore Distance b/w Center
01 200 200 1400
02 290 250 2900
03 220 220 1500
04 350 350 4100
05 250 250 1400
06 700 700 2000

We can Do

photo_2_2024-03-08_16-23-26
photo_3_2024-03-08_16-23-26
photo_4_2024-03-08_16-23-26
photo_1_2024-03-08_16-23-26
milling
Table Design
Specifications
Machine X - Travel Y - Travel Z - Travel
01 500 300 400
02 700 300 400
03 600 250 350
04 700 250 300
05 1000 300 350

We can Do

photo_2_2024-03-08_17-45-28
photo_1_2024-03-08_17-45-28
photo_4_2024-03-08_17-45-28
photo_3_2024-03-08_17-45-28
gear
Table Design
Specifications
S NO Description Parameters
01 X – Travel (mm) 300
02 Y – Travel (mm) 300
03 Z – Travel (mm) 300
04 Minimum Module (mm) 1
05 Maximum Module(mm) 6

We can Do

photo_2_2024-03-08_17-51-20
photo_1_2024-03-08_17-51-20
cylinder
Table Design
Specifications
Distance B/w Center Swing Diameter
1200 500

We can Do

photo_2_2024-03-08_17-51-20
photo_1_2024-03-08_17-51-20
surface
Table Design
Specifications
X Y Z
500 500 200

We can Do

photo_2_2024-03-08_17-51-20
photo_1_2024-03-08_17-51-20
